16k lb GVWR Bumper Pull Dump Trailer
| 7'x12' Dump Trailer with 24" sides | $6,995 |
| 7'x14' Dump Trailer with 24" sides | $7,395 |
| 7'x16' Dump Trailer with 24" sides | $7,995 |
16k lb GVWR Bumper Pull Dump Trailer
| G.V.W.R.: | 16,000 lbs |
| Empty Trailer Weight: | 3,900 lbs (14' trailer with no additional options) |
| Net Payload Capacity: | 12,100 lbs (14' trailer with no additional options) |
| Axles: | Dual 8,000 lb Direct Lube 8 lug (electric brakes on both axles)  |
| Suspension: | Heavy Duty Slipper Spring Suspension  |
| Brakes: | All wheel electric brakes on all axles (12" x 2" brake shoe)  |
| Tires: | New 16" ST235/85R16 14ply radial LRG (4,000lbs ea)  |
| Wheels: | 16" x 6" eight hole white or silver (based on stock)  |
| Main Frame: | 6" x 2" x 3/16" wall rectangular tubing  |
| Tongue: | 6" channel  |
| Tilt Frame: | 3" x 2" x 3/16" wall rectangular tubing  |
| Cross Members: | 3" channel  |
| Bed Flooring: | 1/8" thick sheet steel  |
| Bed Siding: | 1/8" thick sheet steel  |
| Tie Downs: | Stake pockets & D-Rings  |
| Deck width: | 82"  |
| Deck Length: | 12', 14' or 16'  |
| Deck Height: | Approximately 26"  |
| Side Wall Height: | 24" standard  |
| Rear Doors: | Double swing doors (open like barn doors)  |
| Battery: | Group 24 deep cycle marine  |
| Charging System: | Onboard 110v charger and tester (also charges off truck while being towed)  |
| Pump: | Electric over hydraulic (1.7 gpm) - power up / power down  |
| Controller: | 15' corded remote control  |
| Toolbox: | Front locking tool box - contains battery and pump  |
| Hydraulics: | Multi stage trunnion mount telescopic cylinder  |
| Coupler: | 4 hole adjustable height 2 5/16" ball  |
| Safety Chains: | Two heavy duty safety chains  |
| Jack: | 7,000 lb drop leg jack  |
| Fenders: | 14ga heavy duty tread plate  |
| Lighting: | All flush mount or recessed lifetime LED stop / turn / clearance lighting  |
| Wiring: | U.S. made sealed modular wiring harness  |
| Safety Equipment: | DOT required emergency break-a-way kit and conspicuity tape & Prop Rod  |
| Finish: | Fully primed and painted with automotive grade acrylic enamel  |
16k lb GVWR Bumper Pull Dump Trailer
| 16" 14ply mounted spare tire and rim: | $200 × 16" 14ply mounted spare tire and rim: $200  |
| 17.5" 16ply mounted spare tire and wheel: | $250 × 17.5" 16ply mounted spare tire and wheel: $250 |
| Upgrade from 14ply to 16ply tires: | $75/ea ($300 total) |
| 36" sides add: | $350  |
| 48" reinforced sides add: | $800  |
| 60" reinforced sides add: | $1,200  |
| Pair of 5' steel ramps for loading equipment | $300  |
| Pair of 6' aluminum ramps for loading equipment | $600  |
| Upgrade cross members (12" on center): | $300  |
| Barn door and spreader combo gate (up to 36" tall): | $300 |
| Barn door and spreader combo gate (48" tall): | $500 |
| 3/16" upgraded flooring (50% thicker): | $600  |
| Deluxe manual roll up tarping system: | $600 |
| Lodar ® long range two function wireless remote: | $350  |
| 7amp solar charging panel: | $300  |
| Red, blue, orange, green or yellow paint: | $250 |
| Pintle ring along with 2 5/16" ball coupler: | $50  |
| Dual Ram Hoist: | $500  |
